Output current

<400A

Input voltage

3~ 400VAC

Input frequency

50/60 Hz

Input connector

3P+1N+1PE

Output voltage

150~1000VDC

No of charging guns

2/4

Output power per gun

Evenly distributed within, maximum power limiting

Charging connector type

CCS2

Installation

Ground installed

HMI

7-inch touch screen

Charging options

Automatic full, fixed energy, fixed money, fixed time

Payment methods

RFID card, Scan code, VIN kod, (Payment terminal is optional)

Network connection

4G, (Ethernet is optional)

Network communication protocol

OCPP 1.6J

Charging standards

IEC 61851-23, ISO 15118-2

IP rating

IP 54

Operating temperature

-35°C ~ +55°C

Cooling method

Air cooling

Noise

≤ 70 dB

Relative humidity

5% ~ 95%

Safety and protection

overload protection, short circuit protection, current leakage protection, lightning surge protection, grounding protection, anti-static protection, over and under voltage protection, over and under temperature protection, emergency stop, insulation control

Cable management

Cable booster on the top
