Product models

PS110

Battery capacity

110kWh

Rated power

60kW

Rated voltage

537V

Input voltage AC

3~ 400VAC

Input frequency AC

50/60 Hz

Input connector AC

CEE 3~, 63A

Input connector DC charging

CCS2

Output connector AC

CEE 3~ 63A, 32A, 16A; CEE 1~ 16A

Output connector DC charging

CCS2, 1pc

Output power DC charging

60kW

Output voltage DC

150~1000VDC

Cooling method

air cooling

Noise

≤ 70dB

Communication protocol

OCPP 1.6J

HMI

7-inch touch screen

Charging mode

Automatic full, fixed amount, fixed time

Payment method

RFID card, Scan code, APP

Installation

Ground installed or mobile

Charging standards

IEC 61851-23, ISO 15118-2

IP rating

IP 54

Operating temperature

-35°C ~ +55°C

Relative humidity

5% ~ 95%

Network connectivity

4G, Ethernet

Safety and protection

Over and under voltage protection, overload protection, current leakage protection, over temperature protection, low temperature protection, grounding protection, lightning surge protection, anti-static protection, emergency stop, insulation control

Other features

Built in STS function for automatic switching of power supply from grid and battery, and automatic sensing of on grid and off grid;
Built in EMS for automatic self battery charging, and automatic battery discharging for AC output.

MPPT for PV integration

Optional, up to 60kW

Payment terminal

Optional

Inward placing of the charging guns

Optional

Weight

1200kg
